Main Technical data
___________
Designer
Germán Frers Naval Architecture
CE category
A — Unlimited ocean voyages
Hull length
15.23 m / 50’ 0”
Maximum length
16.34 m / 53’ 7’’
Waterline at rest
14.80 m / 48’ 7’’
Beam without rubrail
4.98 m / 16’ 4”
Beam with rubrail
4.99 m / 16’ 5”
Draught, empty standard boat
* 2.35 m / 7’ 8 1/2”
* Also available as a shallow draught version
Displacement, empty standard boat
21 t / 46 300 lbs
Keel weight
7.4 t / 16 350 lbs
Sail area with genoajib, standard boat
131.5 m² / 1 410 ft²
Air draft, ex Windex
24.9 m / 81’ 8’’
Engine
Yanmar 4JH110CR
Power at crank shaft
81 kW / 110 HP
Transmission
Hydraulic with shaft
Diesel
1000 l / 264 US gallon
Fresh water
940 l /248 US gallon
Transport hight, lowest point of keel to pedestal heads
4.92 m / 16′ 2»
Estimated GRT
32.67
Estimated NRT
29.41
