HALLBERG-RASSY 69

Main Technical data

___________

CE category
A — Unlimited ocean voyages

Hull length
17.44 m / 57’ 4”

Maximum length
18.44 m / 60’ 6’’

Waterline at rest
16.77 m / 55’ 0’’

Beam without rubrail
5.11 m / 16’ 9”

Beam with rubrail
5.15 m / 16’ 11”

Draught, empty standard boat *
2.43 m / 8’ 0”

Displacement, empty standard boat
28 t / 61 730 lbs

Keel weight
9.9 t / 21 830 lbs

Keel type
lead on deep bilge
* Also available as a 38 cm/1’3» more shallow draught version

Sail area with genoajib, standard boat
163 m² / 1 755 ft²

Sail area, optimized main and genoajib
181 m² / 1 948 ft²

Air draft, ex Windex
26.9 m / 88’ 4’’

Engine
Volvo Penta D4-175

Diesel
1050 l / 277 US gallon

Fresh water
1030 l /271 US gallon

Transport height including windscreen
5.23 m / 17′ 2»
